CPU Support: Intel® socket 1151, support Intel i3/i5/i7series CPU
Chipset: Intel H310 Chipset
On-Board Graphics: Integrated Graphics Processor-Intel® HD Graphics support
Memory: Dual Channel DDR4 2133/2400/2666/3200MHz (Max. Supports up to 32GB Memory)
DIMM: 2 x Memory Slots
LAN: Onboard Realtek® RTL8111e 1000LAN
Audio: Chip integrated by Realtek 662 on board, Supports 6-channel audio-out
SATA: 3 x SATA 3.0 port, 1 x M.2,1X WIFI SLOT
Internal I/O:
2 x USB 2.0 header supports additional 4 USB 2.0 ports
1 x USB 3.0 header supports additional 2 USB 3.0 ports
1 x Front Panel Audio header
Expansion Slots: 1 x PCI Express x16 slot
Form Factor: Micro-ATX (19.7 x 17 cm)
OS Support: Support Windows 7 / 8 / 8.1 / 10(x64)
Mounting: 6 mounting holes
